2LINE Customer Outlet Box COB
Optic fibre management system
2LINE COB S
.png)
- Installation of E&MMS cassette system and patch field for the accomodation of adapters
- Variable extension for splicing or patching
- Different sizes (S,M,L) available
The 2LINE COB is a modular fibre optic distribution system for splicing and patching of optical fibres. It is used in buildings, smaller control cabinets and as outdoor distribution boxes. There is a wide range of different configuration possibilities.
.png)
Facts
Advantages:
- Possibility to install splitters
- Inlet / outlet for cables / pipes with Ø3 to Ø20mm
- Possibility of depositing excess loose tube length and cable loop
- Removable protective hood
- Suitable for indoor and outdoor use
- Easy access and installation
- Simple wall installation
- Closure: lock
Scope of delivery:
- 1 pc. 2LINE COB S
- Adapters and pigtails (optional)
- Cable bushings (Ø1.5 - 35mm) (optional)
- Splice cassettes (crimp or shrink splice protection) (optional)
- Cassettes with PLC splitters (optional)
- Patch panel for max. 24 couplings (optional)
- ZEA (central interception element) (optional)
Dimensions:
- HxWxD[mm]: 440x265x150
Tests/Standards:
- Impact resistance class IP54
Downloads
No downloads available
Tender specifications
Variants
| Dimension | Order ref. | Article no. | |
|---|---|---|---|
| 540x265x160 | 2LINE COB Gr. S | 21508 |   |
